Offered Products
Equipment offered includes,
Water control gates, Mechanized screening systems, Screening conveying and washing systems, Knife gate valves, Water hammer control valves, Energy dissipating valves, Archimedes screw pumps, Micro hydro turbines, Clarifiers, Clariflocculators, Flash Mixers, Degritters, Aerators, Thickeners, Gravity Decanters, Trickling Filters, Digester Mixers, DAF Units and solid handling valves.
Version Mono
Primarily used in underground installation, chamber installation and in sewage and water systems
Material of construction is Cast Ductile Iron per ASTM A 536 Gr.65-45-12 or 400/15 (GGG40)
Valves are manufactured per WECO standard
Flange is DIN PN 10 (To suit mount between IS 1538 – 1993)
Sizes vary from DN 80 to DN 300
Resilient and Metallic seatings available
Actuated by manual, electric, hydraulic and pneumatic actuators
Version Mono-A
Primarily used in underground installation, chamber installation, sewage & water systems and for drinking water applications
Material of construction is Cast Ductile Iron as per ASTM A 536 Gr.65-45-12 or 400/15 (GGG40)
Valves are manufactured per AWWA C520-10 Standard
Flange is DIN PN 10 (To suit mount between IS 1538 – 1993)/ANSI 150 B 16.5
Sizes vary from DN 80 to DN 600
Resilient and Metallic seatings available
Actuated by manual, electric, hydraulic and pneumatic actuators
Version Mono-T
Primarily used in underground installation, chamber installation, sewage & water systems and for drinking water applications
Material of construction is Cast Stainless Steel ASTM A 351 Gr. CF: 8 / CF: 8M
Valves are manufactured per AWWA C520-10 Standard / TAPPI-805
Flange is DIN PN 10 (To suit mount between IS 1538 – 1993)/ANSI 150 B 16.5
Sizes vary from DN 80 to DN 600
Resilient and Metallic seatings available
Actuated by manual, electric, hydraulic and pneumatic actuators
Version Mono-C
Primarily used in underground installation, chamber installation, sewage & water systems and for drinking water applications
Material of construction is Cast Iron per ASTM A 126 Gr. Class B
Flange is DIN PN 10 (To suit mount between IS 1538 – 1993)/ANSI 150 B 16.5
Sizes vary from DN 80 to DN 600
Resilient seating available
Actuated by manual, electric, hydraulic and pneumatic actuators
Version ZFI M
Primarily used in underground liquid, solid and solid-liquid mixes
Material of construction is Cast Iron, Cast Carbon Steel and Cast Stainless Steel, per MSS SP-81
Flange is DIN PN 10/ANSI 150 B 16.5
Sizes vary from DN 80 to DN 600
Metallic seating available
Actuated by manual, electric, hydraulic and pneumatic actuators
Version ZFI S
Primarily used in underground liquid, solid and solid-liquid mixes
Material of construction is Cast Iron, Cast Carbon Steel and Cast Stainless Steel, per MSS SP-81
Flange is DIN PN 10/ANSI 150 B 16.5
Sizes vary from DN 80 to DN 600
Resilient seating available
Actuated by manual, electric, hydraulic and pneumatic actuators
Version ZFI SRR
Primarily used in underground liquid, solid and solid-liquid mixes
Material of construction is Cast Iron, Cast Carbon Steel and Cast Stainless Steel, per MSS SP-81
Flange is DIN PN 10/ANSI 150 B 16.5
Sizes vary from DN 80 to DN 600
Resilient seating available
Actuated by manual, electric, hydraulic and pneumatic actuators
With Jash, the company offers a single stop solution under one roof including Design, Casting, Fabrication, Assembly & Testing and provides the most varied range of these products in largest possible sizes.
To ensure this, Jash is continuously investing in its manufacturing capability as well as in development of new products & technologies either on its own or through collaboration with suitable technology partners and leaders in the trade.
With over 6 decades of excellent engineering and manufacturing experience, today Jash is an industry leader in India for most of these products and also exports these products to over 30 countries world wide.
